The Xeltek SuperPro IS416N is a high-speed, universal ISP gang programmer designed to efficiently program up to 16 serial devices simultaneously. With support for various serial protocols and the capability to program up to 4 parallel devices like eMMC, NAND, and NOR FLASH concurrently, it's ideal for high-volume production environments. eVision Webshop+4testech-elect.com+4microport.com.tw+4eVision Webshop+5xeltek.com+5microport.com.tw+5
🚀 Key Features
-
16-Channel Concurrent Programming: Program up to 16 serial devices simultaneously, enhancing throughput in production settings.eVision Webshop+4testech-elect.com+4microport.com.tw+4
-
Parallel Device Support: Capable of programming up to 4 parallel devices (eMMC, NAND, NOR FLASH) concurrently.beti.com.tr+7xeltek.com+7xeltek.com+7
-
Versatile Operation Modes: Supports USB online, network online, and offline modes via SD card, providing flexibility for various workflows.xeltek.com+2testech-elect.com+2xeltek.com+2
-
Protocol Compatibility: Supports a wide range of serial protocols, including I2C, SPI, UART, BDM, MW, JTAG, CAN, and RS232.
-
High-Speed Programming: Utilizes FPGA-based architecture and manufacturer-approved algorithms to ensure rapid and reliable programming.
-
Mass Production Mode: Automatically initiates programming upon detecting the target board is ready, streamlining the production process.
-
Expandable Configuration: Up to 16 programmers can be connected to a single PC for programming multiple PCBs or used in stand-alone mode.Steven Rhine - Rhine Labs Blog / News+10microport.com.tw+10xeltek.com+10
-
Adjustable Programming Speed: Features adjustable speed settings to accommodate various industrial applications and cable lengths up to 3 feet (1 meter).xeltek.com+4isit.fr+4testech-elect.com+4
-
Advanced Software Features:
-
Project Files: Store device type, buffer data, operation settings, and batch commands for streamlined operations.
-
Auto Function: Execute sequential operations like erase, blank check, program, verify, and protect with a single command.
-
Auto Increment: Automatically generate and increment serial numbers for each programmed chip.
-
Factory Mode: Designed for volume production with password protection to prevent unauthorized access.
-
Safety and Reliability: Features over-current and over-voltage protection, Vcc verification, and ESD protection to ensure the safety of both the chip and programmer hardware.
📦 What's Included
Note: Additional accessories and socket adapters are available separately.
🛠️ Optional Accessories
-
ISP Cables
-
System Control Cable
-
Additional SD Cards
-
LAN Cablexeltek-cn.com
🎯 Ideal For
-
Programming houses
-
Electronic repair shops
-
Automotive repair centers
-
Forensic and data recovery companies
-
Medical device manufacturers
Experience unparalleled programming speed and versatility with the Xeltek SuperPro IS416N. Whether you're in development, production, or field applications, this universal in-system programmer is designed to meet your needs with efficiency and reliability.
Certifications: CE Compliant, RoHS Compliant, ISO 4001
