GW Instek - GCM 01 - Insulation Tester

GW Instek GCM-01

AC/DC Voltage, AC Current, Resistance Audible Continuity Check and Insulation Test

1000A High Current Range

0.5% DCV Accuracy

Specifications

AC Voltage

Range – 750V

Bandwidth – 50Hz-400Hz

Accuracy - +/- (1.5% rdg + 5 digits)

AC Current

Range – 200A,600A

Accuracy- 50Hz – 60Hz +/- (2% rdg + 5 digits)

Resistance

Range – 200Ω, 20Ω 2 ranges

Accuracy – 200Ω +/- (1% rdg +3 digits), 20Ω +/- (1% rdg + 1 digit)

Audible Continuity Check

Range – 200Ω

Insulation Test Option

Range – 20MΩ, 2000ΩM 2 Ranges

Accuracy – 20MΩ +/- (2% rdg + 2 digits), 200MΩ-500MΩ +/- (4% rdg + 2 diigits), 500MΩ-2000MΩ +/- (5% rdg + 2 digits)

Test Voltage – 500VDC

Power Source – Single Standard 9V Battery NEDA 1604 JIS006P, IEC 6F22
